XY-TC-H750 350
technical parameters
model: XY-TC-H 750 350
rim diameter: 13-26"
Tires: 13"
Tire diameter: 1050MM
Power supply: 220/380V
Working pressure: 0.8-1.0Bar
speed: 1-13/6.18-13 r/min
Motor power: 0.7-0.9/1.5KW
Noise:<70dB
Weight: 410KG
Show Details
 |
 |
 |
||
| Manual without crowbar device | without plate | aluminum 200 cylinder |
 |
 |
 |
||
| Oil-water separator | Inflator | Tire Installation |
Dimensions (Unit: mm)
Note: Product pictures are for reference only. Produces different voltages and colors.
1. Vertical Column: Save Time/Energy/Space
2. Hexagon rod: easy hub alignment
3. No anti sliding head: hard tire safety
4. Composite box: reduce swing momentum
5. Alloy pedal valve: durable
6,220V servo/380V 2-speed motor: low noise, high efficiency
7. Integrated lift: save time/effort
8. 3-Pressure bar: suitable for all tire widths
9. Nylon pad: Scratch-resistant hub protection
2. Hexagon rod: easy hub alignment
3. No anti sliding head: hard tire safety
4. Composite box: reduce swing momentum
5. Alloy pedal valve: durable
6,220V servo/380V 2-speed motor: low noise, high efficiency
7. Integrated lift: save time/effort
8. 3-Pressure bar: suitable for all tire widths
9. Nylon pad: Scratch-resistant hub protection
